Cima S.p.A has a highly flexible production capacity, which meets the specific needs of its customers thanks to the constant investment in innovation.
The company boasts a wide machinery range, that is divided into four production units and consists in:

N°	Machinery	Characteristics
1	C.N.C Cutting Table	Width = 3.000 mm x Length = 12.000 mm	Oxy-fuel > Thk = 3 - 300 mm
		Width = 3.000 mm x Length = 8.000 mm	Plasma > Thk = 3 - 70 mm
1	Rotary Table Positioner	Horizontal capacity >
		15.000 kg
		6.000 kg
		3.000 kg
		1.500 kg
		700 kg
1	Roller Positioner	Capacity >
		44.000 kg
		35.000 kg
		16.000 kg
		12.000 kg
		6.000 kg
6	Three Rollers Calendar	Thk = 110 mm	Width = 3.200 mm
		Thk =   60 mm	Width = 3.200 mm
		Thk =   40 mm	Width = 3.200 mm
		Thk =   30 mm	Width = 1.500 mm
		Thk =   18 mm	Width = 1.500 mm
		Thk =     5 mm	Width = 2.000 mm
4	Bending machine for pipes
4	Sub-Arc Welding Manipulator	From 4 to 5 m with generators from 1.000 A to 1250 A
23	Wire Welding Machine
9	Electrode Welding Machine
3	TIG Welding Machine
5	Portable fume extractor
4	Stationary fume extractor
4	Flux hopper Oven
5	Electrode Oven
1	Oven for controlled heating for hot assembly
3	Portable generators for plasma cutting	Thicknesses up to 50 mm
1	Facing lathe with tailstock	Turnable Diameter = 2.500 mm x Length = 4.000 mm
		Turnable Diameter = 4.100 mm x Length= 900 mm
1	Lathe with double carriage	Turnable Diameter on the carriage = 800 x Length= 8.200 mm
		Turnable Diameter under the carriage = 1.600 mm x Length = 800 mm
1	Vertical Lathe	Table Diameter = 4.000mm
		Turnable Diameter = 5.200 mm x Height = 3.000 mm
1	Vertical Lathe	Table Diameter = 2.500 mm
		Turnable Diameter = 2.700 mm x Height = 1.500 mm
1	Vertical Lathe	Table Diameter = 1.500 mm
		Turnable Diameter = 1.500 mm x H = 900 mm
1	Parallel Lathe	Turnable Diameter on the carriage = 1.200 x Length= 2.500 mm
		Turnable Diameter under the carriage = 1.600 mm x Length = 500 mm
1	Parallel Lathe	Turnable Diameter on the carriage = 500 x Length = 3.000 mm
		Turnable Diameter under the carriage = 850 mm x Length = 400 mm
1	C.N.C. Boring machine	Table > 1.500 mm x 1.270 mm
		Strokes > X:2.500 mm Y:1.800 mm Z:1.500 mm
1	Boring machine	Table > 1.500 mm x 1.250 mm
		Strokes > X:1.900 mm Y:1.600 mm Z:800 mm
1	Boring machine	Table > 1.100mm x 900 mm
		Strokes > X:1.500mm Y:1.200 mm Z: 600 mm
1	Shearing machine	Thickness = 10 mm Width = 3.000 mm
1	Bending Press	250 ton
		Thickness= 10 mm Width. 3.000 mm
1	Grantry press machine	250 ton
1	C-Lamp press	250 ton
6	Pillar Drill
5	Radial Drill
4	Multimatic Punching Machine
29	Overhead travelling Crane	Maximum Weight > up to 29 ton
4	Lifter	Maximum Weight > up to 3.500 kg
20	Jib Crane	Weight = 200 - 500 kg
3	Mobile Crane	Maximum Weight > up to 12 ton
